ADVANTAGES
-Fastest in this segment with 330 scans per second
-Increased resolution of 2500 pixels
-Greater decoding accuracy
-Auto-scan mode enables hands-free operation
-Higher depth-of-field up to 300 mm enables decoding from longer distances
AIM & SHOOT TRIGGER PROVIDING OPERATIONAL COST
DURABLE AND
STRONG DESIGN
ENABLED WITH ULTRA SCAN-DECODING TECHNOLOGY
EXPRESS SPEED AT 330 SCANS PER SECOND
PLUG AND PLAY –
EASY TO INSTALL
SPECIFICATIONS
Light Source
650 nm visible laser diode VLD
MPU
32 bit
Depth of Field
35 200 mm UPC/EAN 100%, PCS=90%
Scan Rate
330 scans per second
Scan Angle
52°
Pitch / Roll / Skew angle
65° / 30° / 65°
Minimum Bar Width
4 mil @ PCS=90% Code 39
Print Contrast
30% @ UPC/EAN 100%
Indicators LED
Three colour LED green, red & blue
Beeper Option
Programmable tone & beep time
System Interfaces
Keyboard, RS232C, HID USB, wand
Physical Dimensions
L106.7 x D58.0 x H155.0 mm device only
Weight
148 g stand excluded
Cable
Standard 2.0M straight
Input Voltage
5 VDC ±10%
Power Consumption
1.0 watts
Operating Current
200 mA
Laser Class
CDRH Class Iia: IEC 608251: Class 1
EMC
CE & FCC DOC compliance, VCCI, BSMI
Storage Temperature
Light Levels
4,500 Lux fluorescence
Drop Durability
Designed to withstand 1.0 M drops
Barcode
Most popular 1D barcodes, incl. GS1 DataBar & PDF 417
